HORMANN THERMA TECH 3500

HORMANN THERMA TECH 3500

The Therma Tech 3500 (formerly marketed as Therma Tech II) has an insulation value of 10.4. It features a sandwich construction, a flexible joint seal and a natural Thermal Break.
Six wood grain textured panel designs are available:

  1. Short Raised (Model 218)
  2. Long Raised (Model 228)
  3. Shaker (20SI)
  4. Country (Model 20C)
  5. Cottage (Model 20G)
  6. Flush (Model 208)

Doors are hot-dipped galvanized, primed, then pre-painted in one of five standard colors:

  1. Bright White
  2. Almond
  3. Sandstone
  4. Brown
  5. Black

Our Short Raised, Long Raised , Shaker, Country, and Cottage Panels are also available in a Dark and Medium wood grain finish. Choose from a wide selection of window designs.

Product Details

GENERAL INFORMATION

  • Section Joint: Tongue and Groove joint between sections with Thermal Break
  • Flexible Vinyl Joint Seal
  • 2″ thick EPS, *R=10.4
    * R values are calculated specifically for the colder climates and offer the best long term insulating value.
  • Panel Types / Size (Approximate)
    • Flush Wood Grain
    • Short Raised size: 19″ x 15″
    • Long Raised size: 42″ x 15″
    • Shaker size: 42″ x 15″
    • Country size: 19″ x 15″
    • Cottage Panel size: 42″ x 15″
  • Finish: Baked on polyester enamel
  • Colors selection: Bright White, Brown, Almond, Sandstone, Black
    • Dark  & Medium wood grain available on Short Raised, Long Raised , Shaker, Country, and Cottage Panels
  • Bottom weather seal: U-shape loop type vinyl with adjustable aluminum retainer
  • Limited Lifetime Warranty

STANDARD WIDTHS

8′-0″, 9′-0″, 10′-0″, 12′-0″, 14′-0″, 15′-0″, 16′-0″, 18′-0″, 20′-0″

STANDARD HEIGHTS

7′-0″, 8′-0″, 9′-0″, 10′-0″, 11′-0″, 12′-0″, 14′-0″

HARDWARE

15″ or 12″ radius torsion hardware; track is 2″ bracket mounted. Durable nylon rollers, non corrosive door fixtures and graduated hinges are standard. U-shaped galvanized struts are supplied with every double car door to keep the door rigid.

500 Series Cutaway Diagram9 2019

OPTIONS

RECOMMENDED OPTIONS

Extended Life Package

  • 25,000 Cycle Torsion Springs
  • Nylon Ball Bearing Rollers
  • Heavy Gauge Hinges
  • Heavy Duty Cables

Insulated Glass

LiftMaster Model 84501 Opener



OTHER OPTIONS



  • 15 Window Designs
    • Arched Stockbridge
    • Arched Stockton
    • Cascade
    • Cathedral
    • Diamond
    • Modern Lite LH
    • Modern Lite RH
    • Plain Lite
    • Prairie
    • Sherwood
    • Stockbridge
    • Stockbridge/Arched Stockbridge Combination
    • Stockton
    • Stockton/Arched Stockton Combination
    • Williamsburg
  • Glass Options
  • Low Clearance, High Lift, or Vertical Lift Hardware
  • Angle Mounted Track
  • Double End Hinges and Long Stem Rollers
  • 25,000, 50,000 and 100,000 Cycle Torsion Springs
  • Deco Hardware Kit B & Deco Hardware Kit C on Carriage Panel only
  • Powder Coated Hardware
